– SMD to DIP Breakout PCB Module, 8-Pin, SOIC to DIP Adapter Header with Integrated SMT Resistor and/or Capacitor Pads – 10 Pieces by Custom Circuit Solutions

Custom Circuit Solution’s SMT to DIP solderable breadboard prototype modules are much more than a traditional SMT breakout PCB. They offer many benefits including flexible mounting options with dual rows of solderable holes, the ability to incorporate passive devices directly on board (such as 0603/0805 footprint passive components), as well as oversized pads to simplify hand soldering. By incorporating most or all of the circuit’s components directly onboard, you not only make the circuit reusable, it also becomes more reliable, and the signal quality is vastly improved with the minimized lead parasitics when compare to through hole passives plugged into a solderless breadboard. A localized ground/common plane underneath the SOIC-8 device is also included. This allows you to use SOIC-8 devices that require a bottom thermal pad connection, which can be soldered with a standard soldering iron, given the pad extensions beyond the end of the device. This specific module is for SOIC narrow components only. Wide body SOIC devices may be used but will require bending the pins underneath. Alternative sized versions are available if necessary. This SMD header can mount directly to standard breadboards or can be wire jumped directly to other circuits. These devices are beneficial for professional engineers and home hobbyists alike. Stock your makerspace lab with these today.
