Discover the authentic 0.95 Inch 7 Pin Colorful 65K SPI OLED Display Module SSD1331 96 * 64 Resolution for Arduino 51 STM32 by HiLetgo, part of our Single Board Computers collection. Imported directly from the USA and sourced from trusted suppliers, this product is 100% authentic and delivered anywhere in India at the best price.
Highlights & Benefits
- Original Single Board Computers – 0.95 Inch 7 Pin Colorful 65K SPI OLED Display Module SSD1331 96 * 64 Resolution for Arduino 51 STM32 by HiLetgo
- 100% authentic and sourced from trusted suppliers
- Imported from the USA with strict quality checks
- Available at the best price in India
- Fast and secure delivery across the country
1.GND-Gound
2.VCC-Positive Voltage(2.8-5.5V)
3.SCL-Clock Line
4.SDA-Data Line
5.RES-Reset
6.DC-Data/Demand
7.CS-Chip Select
The use of OLED technology offers the following advantages for flat-panel displays
1. A simplified manufacturing process compared to TFT-LC
2. Self-emitting light, in contrast to the required backlight for TFT-LCD
3. High luminosity
4. Lightweight and thin
5. Capable of wide viewing angles
6. Low operating voltage and power consumption
7. Quick response
8. Wide range of operating temperatures (-40c to 85c)
How Does OLED Emit Light
OLEDs basic structure consists of organic materials positioned between the cathode and the anode, which is composed of electric conductive transparent Indium Tin Oxide (ITO). The organic materials compose a multi-layered thin film, which includes the Hole Transporting Layer (HTL), Emission Layer (EML) and the Electron Transporting Layer (ETL). By applying the appropriate electric voltage, holes and electrons are injected into the EML from the anode and the cathode, respectively. The holes and electrons combine inside the EML to form excitons, after which electroluminescence occurs. The transfer material, emission layer material and choice of electrode are the key factors that determine the quality of OLED components.
Package Included:
1* SSD1331 0.95 Inch 7 Pin Full Color 65K SPI OLED Display Module
- Main Driver:SSD1331
- Resolution:96*64
- 0.95 inch Colorful OLED
- Draw speed is responsive
- Easy to Set Up: Easy to work with and requires no soldering for the header pins
- Item Dimensions: Width: , Height: , Length:
- Item Package Dimensions: Width: 5.6896 centimeters, Height: 9.4996 centimeters, Length: 1.905 centimeters
| Attribute | Value |
|---|---|
| item package quantity | 1 |
| interface type | SPI |
| brand | HiLetgo |
| item type keyword | single-board-computers |
| number of items | 1 |
| part number | 3-01-1401 |
| item package weight | 0.009 |
| manufacturer | HiLetgo |
| model number | 3-01-1401 |
| display | |
| batteries required | False |
| product site launch date | 5/19/2017 6:25:50 AM |
| material | FR4 |
| batteries included | False |
