Discover the authentic 48V Charger Output 54.6V 1.5A Ebike Charger 48V 3-pin XLR Male Plug for 48 Volt Electric Bike Charger 13S 48v 12Ah Battery Charger Lithium Battery Pack by TANGSPOWER, part of our Battery Chargers collection. Imported directly from the USA and sourced from trusted suppliers, this product is 100% authentic and delivered anywhere in India at the best price.
Highlights & Benefits
- Original Battery Chargers – 48V Charger Output 54.6V 1.5A Ebike Charger 48V 3-pin XLR Male Plug for 48 Volt Electric Bike Charger 13S 48v 12Ah Battery Charger Lithium Battery Pack by TANGSPOWER
- 100% authentic and sourced from trusted suppliers
- Imported from the USA with strict quality checks
- Available at the best price in India
- Fast and secure delivery across the country
Protections: Short circuit / Overload / Over voltage
LED Display: Red: In charging state, Green: Full Charged
Charge Mode: CC to CV
Use: lithium battery charger
Input Voltage: 100-240 V 50/60 HZ
Suitable Voltage / Frequency: 90-264 V 47 / 63Hz
Output Voltage: 54.6 V
Output current: 1.5A / 3A(select)
Power: 81.9 W
Productivity: 80%
Fluctuation / Noise: <100MV
Working temperature: 0-40 ° C
Storage Temperature: -20-85 ° C
Working Nemi: 5% ~ 90% RH
Storage Humidity li ion battery charger: 5% ~ 90% RH
Housing material: PC
Use and maintenance of the charger :
1. When charging, first connector to the battery, then connect to AC; after full, cut off AC,
then pull the battery plug. If you pull the battery plug first while charging, especially when
the charging current is large (red light), it is very easy to damage the charger.
2. LED display after turning green, then charge for 2-3 hours.
3. Please do not run out of battery power, then charger. Otherwise the battery cannot
be protected or even damaged. 4. long-term shallow discharge battery, about 3 months, for a deep discharge, is the
so-called re-lighting, which is conducive to the activation of long-term immobile material in
the deep part of the battery. Luminous means that riding the controller battery undervoltage
protection action 5. If your battery has not been used for a long time (2-3 months), please charge
the battery beforeusing it. Make sure your battery is not broken.
6.Please use the charger in a dry place in time.
7.When you do not use the charger, do not always connect the power supply.
8.Please confirm your battery, Because it is used to charge the lithium battery.
Do not use the charger on the LiFepo4 battery, otherwise the charger will be got incredibly hot.
- 48v ebike battery charger, Input:100-240VAC,50/60Hz 84W Output:54.6V-1.5A, XLR-3Pin :1means +, 2 means -, “3”means ground, The plug's Diameter is 18mm, please check the size before order.
- 105 Output capacitor, global applicable AC Input voltage.100% full load aging test, Internal EMI filter, ripple minimum. The precision current between ±0.1A, the voltage tolerance is ±0.1V, absolutely not virtual marking.
- The electric bike charger 48v, Built-in simply fan, with radiating fin surrounding the board, dissipating the heat through the shell, So some hot on the shell when charging is very normal, but it is durable.
- The Charger protected: Short circuit protection/ over current protection/ over voltage protection; red light -- charging, green light -- charge OK, it stop automatically when the battery is full.
- Replace your broken charger or add an extra charger to charge in 2 locations without taking the original charger with you
- Item Weight: 0.358 kilograms
- Item Dimensions: Width: , Height: , Length:
- Item Package Dimensions: Width: 11.6078 centimeters, Height: 18.0086 centimeters, Length: 5.588 centimeters
Attribute | Value |
---|---|
compatible phone models | mobility scooter charger, ebike charger |
item package quantity | 1 |
brand | TANGSPOWER |
item type keyword | general-use-battery-chargers |
recommended uses for product | |
part number | TP-84W-5461500 |
color | Output current 1.5A XLR Male |
item package weight | 0.372 |
battery | |
manufacturer | 54.6v |
amperage | 1.5 |
model number | TP-84W-5461500 |
supplier declared dg hz regulation | not_applicable |
batteries required | False |
voltage | 54.6 |
product site launch date | 10/16/2017 8:38:37 AM |
compatible devices | e-bike battery, 48v 15ah lithium ebike battery, 48v electric trike battery |
unit count | 1 |
batteries included | False |
